Alloy 926 Tubes Supplier

Workings of Alloy 926 Tubes:

The combination of molybdenum and nitrogen resists pitting and crevice corrosion. Also, copper enhances sulfuric acid resistance, and nitrogen improves yield and tensile strength. We manufacture the Alloy 926 Tubes as per the needs of working applications. Alloy 926 is a super-austenitic molybdenum stainless steel with outstanding resistance to highly corrosive environments.

NICKEL ALLOY 926 TUBING MANUFACTURER, ALLOY 926 ERW, SEAMLESS INDUSTRIAL TUBES, UNS N08926, AND 1.4529 TUBES SUPPLIER IN MUMBAI, INDIA.

Properties of Alloy 926 Tubes:

Alloy 926 Tubes have opposition to chloride stress corrosion cracking. In addition, Alloy 926 Tubes have outstanding resistance to highly corrosive conditions. The material combination of Alloy 926 is molybdenum and nitrogen that resists pitting and crevice corrosion, copper enhances sulfuric acid resistance, and nitrogen provides yield and tensile strengths.

Mechanical properties:

  • Modulus of elasticity
  • Elongation at break
  • Rockwell B hardness



Features of Alloy 926 Tubes:

  • The Alloy 926 pipes are perfect for chloride-induced stress corrosion resistance.
  • Increased resistance against stress corrosion in comparison to other austenitic stainless steels.
  • Excellent general corrosion resistance when in contact with oxidizing and reducing media.
  • Higher strength than Alloy.
  • Low propensity to form intermetallic phases.
  • Approval for pressure vessels in the temperature range.

STOCKIST OF UNS N08926 INCOLOY ALLOY 926 RECTANGULAR TUBES, COMPETITIVE PRICE OF ASTM B729 ALLOY 926 SEAMLESS, ERW TUBES IN MUMBAI

Industrial applications of Alloy 926 Tubes:

Alloy 926 Tubes are used in various heavy-duty applications, including chemical storage and processing, aerospace, and the following applications:

  • Desalination systems
  • Pulp and paper industry
  • Food processing equipment
  • Chemical processing plant
  • Offshore oil and gas production
  • Power generation

SUPPLIER INCOLOY 926 CUSTOM TUBES PRICE PER METER, ALLOY 926 WELDED TUBING SPECIFICATIONS, ALLOY 926 TUBES PRICE LIST.

SMM Industries LLP manufactures the best range of Alloy 926 Tubes. The process and methodologies used to manufacture the Alloy 926 Tubes are unique. As a result, they offer superb strength and working properties. The utilized material compositions and qualitative grades provide excellent qualities and great features with Alloy 926 Tubes. These Alloy 926 Tubes perform excellent general corrosion resistance, moderate to high strength, and good weldability. Alloy 926 Tubes also exhibit good durability and have good flexibility and thermal conductivity.

Alloy 926 Tubes

Specification of Alloy 926 Tubes

Specifications

ASTM B729, B468/ ASME SB729, SB468

Manufacturing Techniques

Seamless / Welded / ERW

Seamless Tube Size

1 / 2″ NB – 16″ NB

Schedule Thickness Range

SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS

Outside Diameter

6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock

Tubes End Types

Plain End, Beveled End, Treaded One End, TBE (Treaded Both Ends)

Welded Tube Size

1 / 2″ NB – 24″ NB

Delivery Condition

Annealed and Pickled, Bright Annealed, Cold Drawn

Manufacturing Shapes

Round

Value Added Services

Cutting, Beveling, Threading, Destructive, Non Destructive, Ultrasonic Testing

Stock availability of Alloy 926 Tubes

Seamless Tubes

Alloy 926 Seamless Tubes

  • ASTM B729 Alloy 926 Seamless Tube
  • ASME SB 729 Alloy 926 Seamless Tube
  • Nickel Alloy 926 Seamless Tubes
  • ASTM B729 Alloy 926 Seamless Tubing
  • Alloy N08926 Seamless Tube

Welded Tubes

Alloy 926 Welded Tubes

  • Stainless Steel 926 Welded Tube
  • ASME SB 468 Alloy 926 Welded Tube
  • Alloy N08926 Welded Tubing
  • ASTM B468 Alloy 926 Welded Tube

ERW Tubes

Alloy 926 ERW Tubes

  • Alloy 926 Electrical Resistance Welded Tubes
  • Alloy N08926 ERW Tubing
  • Stainless Steel 926 ERW Tube
  • ASTM B468 Alloy 926 Electrical Resistance Welding Tube

Contact us to get a quick quote

If you require any further information, Please do not hesitate to contact us.

Equivalent Grades Alloy 926 Tubes

STANDARDUNSWERKSTOFF NR.
 926N089261.4529

Chemical Composition of Alloy 926 Tubes

Fe Ni Cr Mo Mn Cu Si N P C S
41.69 – 50.35 24-26 19-21 6-7 2 0.5-1.5 0.5 0.15-0.25 0.03 0.02 0.01

Mechanical Properties of Alloy 926 Tubes

Density Tensile strength Yield strength Elongation at break
8.03 g/cm³ 648 MPa, 94000 psi 296 MPa, 43000 psi 35 %

Alloy 926 Tubes Dimensions Chart

Tube O.D. Tube Gauge
00 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
Wall Thickness (Inches)
0.380 0.340 0.300 0.284 0.259 0.238 0.220 0.203 0.180 0.165 0.148 0.134 0.120 0.109 0.095 0.083 0.072 0.065 0.058 0.049 0.042 0.035 0.032 0.028 0.025 0.022
Tube I.D.
1/4″ N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A N/A 0.010 0.032 0.060 0.084 0.106 0.120 0.134 0.152 0.166 0.180 0.186 0.194 0.200 0.206
3/8″ N/A N/A N/A N/A N/A N/A N/A N/A 0.015 0.045 0.079 0.107 0.135 0.157 0.185 0.209 0.231 0.245 0.259 0.277 0.291 0.305 0.311 0.319 0.325 0.331
1/2″ N/A N/A N/A N/A N/A 0.024 0.060 0.094 0.140 0.170 0.204 0.232 0.260 0.282 0.310 0.334 0.356 0.370 0.384 0.402 0.416 0.430 0.436 0.444 0.450 0.456
5/8″ N/A N/A 0.025 0.057 0.107 0.149 0.185 0.219 0.265 0.295 0.329 0.357 0.385 0.407 0.435 0.459 0.481 0.495 0.509 0.527 0.541 0.555 0.561 0.569 0.575 0.581
3/4″ N/A 0.070 0.150 0.182 0.232 0.274 0.310 0.344 0.390 0.420 0.454 0.482 0.510 0.532 0.560 0.584 0.606 0.620 0.634 0.652 0.666 0.680 0.686 0.694 0.700 0.706
7/8″ 0.115 0.195 0.275 0.307 0.357 0.399 0.435 0.469 0.515 0.545 0.579 0.607 0.635 0.657 0.685 0.709 0.731 0.745 0.759 0.777 0.791 0.805 0.811 0.819 0.825 0.831
1″ 0.240 0.320 0.400 0.432 0.482 0.524 0.560 0.594 0.640 0.670 0.704 0.732 0.760 0.782 0.810 0.834 0.856 0.870 0.884 0.902 0.916 0.930 0.936 0.944 0.950 0.956
1 1/8″ 0.365 0.445 0.525 0.557 0.607 0.649 0.685 0.719 0.765 0.795 0.829 0.857 0.885 0.907 0.935 0.959 0.981 0.995 1.009 1.027 1.041 1.055 1.061 1.069 1.075 1.081
1 1/4″ 0.490 0.570 0.650 0.682 0.732 0.774 0.810 0.844 0.890 0.920 0.954 0.982 1.010 1.032 1.060 1.084 1.106 1.120 1.134 1.152 1.166 1.180 1.186 1.194 1.200 1.206
1 1/2″ 0.740 0.820 0.900 0.932 0.982 1.024 1.060 1.094 1.140 1.170 1.204 1.232 1.260 1.282 1.310 1.334 1.356 1.370 1.384 1.402 1.416 1.430 1.436 1.444 1.450 1.456
1 3/4″ 0.990 1.070 1.150 1.182 1.232 1.274 1.310 1.344 1.390 1.420 1.454 1.482 1.510 1.532 1.560 1.584 1.606 1.620 1.634 1.652 1.666 1.680 1.686 1.694 1.700 1.706
2″ 1.240 1.320 1.400 1.432 1.482 1.524 1.560 1.594 1.640 1.670 1.704 1.732 1.760 1.782 1.810 1.834 1.856 1.870 1.884 1.902 1.916 1.930 1.936 1.944 1.950 1.956
2 1/4″ 1.490 1.570 1.650 1.682 1.732 1.774 1.810 1.844 1.890 1.920 1.954 1.982 2.010 2.032 2.060 2.084 2.106 2.120 2.134 2.152 2.166 2.180 2.186 2.194 2.200 2.206
2 1/2″ 1.740 1.820 1.900 1.932 1.982 2.024 2.060 2.094 2.140 2.170 2.204 2.232 2.260 2.282 2.310 2.334 2.356 2.370 2.384 2.402 2.416 2.430 2.436 2.444 2.450 2.456
2 3/4″ 1.990 2.070 2.150 2.182 2.232 2.274 2.310 2.344 2.390 2.420 2.454 2.482 2.510 2.532 2.560 2.584 2.606 2.620 2.634 2.652 2.666 2.680 2.686 2.694 2.700 2.706
3″ 2.240 2.320 2.400 2.432 2.482 2.524 2.560 2.594 2.640 2.670 2.704 2.732 2.760 2.782 2.810 2.834 2.856 2.870 2.884 2.902 2.916 2.930 2.936 2.944 2.950 2.956
3 1/4″ 2.490 2.570 2.650 2.682 2.732 2.774 2.810 2.844 2.890 2.920 2.954 2.982 3.010 3.032 3.060 3.084 3.106 3.120 3.134 3.152 3.166 3.180 3.186 3.194 3.200 3.206
3 1/2″ 2.740 2.820 2.900 2.932 2.982 3.024 3.060 3.094 3.140 3.170 3.204 3.232 3.260 3.282 3.310 3.334 3.356 3.370 3.384 3.402 3.416 3.430 3.436 3.444 3.450 3.456
3 3/4″ 2.990 3.070 3.150 3.182 3.232 3.274 3.310 3.344 3.390 3.420 3.454 3.482 3.510 3.532 3.560 3.584 3.606 3.620 3.634 3.652 3.666 3.680 3.686 3.694 3.700 3.706
4″ 3.240 3.320 3.400 3.432 3.482 3.524 3.560 3.594 3.640 3.670 3.704 3.732 3.760 3.782 3.810 3.834 3.856 3.870 3.884 3.902 3.916 3.930 3.936 3.944 3.950 3.956
4 1/4″ 3.490 3.570 3.650 3.682 3.732 3.774 3.810 3.844 3.890 3.920 3.954 3.982 4.010 4.032 4.060 4.084 4.106 4.120 4.134 4.152 4.166 4.180 4.186 4.194 4.200 4.206
4 1/2″ 3.740 3.820 3.900 3.932 3.982 4.024 4.060 4.094 4.140 4.170 4.204 4.232 4.260 4.282 4.310 4.334 4.356 4.370 4.384 4.402 4.416 4.430 4.436 4.444 4.450 4.456
4 3/4″ 3.990 4.070 4.150 4.182 4.232 4.274 4.310 4.344 4.390 4.420 4.454 4.482 4.510 4.532 4.560 4.584 4.606 4.620 4.634 4.652 4.666 4.680 4.686 4.694 4.700 4.706
5″ 4.240 4.320 4.400 4.432 4.482 4.524 4.560 4.594 4.640 4.670 4.704 4.732 4.760 4.782 4.810 4.834 4.856 4.870 4.884 4.902 4.916 4.930 4.936 4.944 4.950 4.956
5 1/4″ 4.490 4.570 4.650 4.682 4.732 4.774 4.810 4.844 4.890 4.920 4.954 4.982 5.010 5.032 5.060 5.084 5.106 5.120 5.134 5.152 5.166 5.180 5.186 5.194 5.200 5.206

Alloy 926 Gauge thickness chart

GAUGE THICKNESS RANGE (INCHES) TYPICAL VALUE (INCHES)
22 0.025 through 0.029 0.028
20 0.031 through 0.035 0.035
19 0.038 through 0.042 0.042
18 0.044 through 0.049 0.049
17 0.053 through 0.058 0.058
16 0.060 through 0.065 0.065
15 0.066 through 0.074 0.072
14 0.075 through 0.085 0.083
13 0.087 through 0.097 0.095
12 0.101 through 0.111 0.109
11 0.112 through 0.122 0.12
10 0.126 through 0.136 0.134
9 0.140 through 0.150 0.148
8 0.157 through 0.167 0.165
7 0.175 through 0.185 0.18

Alloy 926 tube outside diameter

NOMINAL PIPE SIZE OD SCH 5 SCH 10 SCH 40 SCH 80
1/2″ 0.84 0.065 0.083 0.109 0.147
3/4″ 1.05 0.065 0.083 0.113 0.154
1″ 1.315 0.065 0.109 0.133 0.179
1-1/4″ 1.66 0.065 0.109 0.14 0.191
1-1/2″ 1.9 0.065 0.109 0.145 0.2
2″ 2.375 0.083 0.109 0.154 0.218
2-1/2″ 2.875 0.083 0.12 0.203 0.276
3″ 3.5 0.083 0.12 0.216 0.3
3-1/2″ 4 0.083 0.12 0.226 0.318
4″ 4.5 0.083 0.12 0.237 0.337
