Inconel 718 Sheets Supplier

Table of Contents

Important material specifications of Inconel 718 Sheets:

Inconel 718 Sheets is nothing but high-strength, corrosion-resistant nickel-chromium. 718 Sheets are manufactured with the superalloy used in various applications due to the wide range of temperatures it can withstand. They are manufactured using niobium, titanium, molybdenum, and aluminum alloys. As a result, sheets provide high durability even in the soaring environment and stress corrosion resistance to chloride and sulfide ions. Inconel 718 Sheets contain a unique chemical mixture that provides exceptional malleability and ductility.

INCONEL 718 COLD ROLLED SHEETS, UNS N07718 SHEETS, ALLOY 718 INDUSTRIAL SHEETS MANUFACTURER IN MUMBAI, INDIA.

Properties and details of Inconel 718 Sheets:

The sheets are made from an age-hardenable alloy that can readily be fabricated, even into complex parts. In addition, its welding characteristics, especially its resistance to post-weld cracking, are outstanding. The functional properties of these sheets are excellent as they have good tolerances levels. Inconel 718 Sheets are ideal for applications that require improved strength and weight reduction. These sheets display high strength and flexibility. The Inconel sheets

offer exceptional tensile and yield strength. It can be quickly hardened by hot working. In addition, these sheets are known for bearing high-compact pressure in applications. The sheets indicate reliability in freezing and high-heat applications. These 718 Sheets have excellent thermal stability and are stress rupture resistant. They can be machined quickly and hence used in many industries. They display outstanding reliability in their performance. They are tolerant of harsh environments.

COMPETITIVE PRICE OF ASTM B670 INCONEL ALLOY 718 SHEETS, INCONEL 718 PERFORATED, HOT ROLLED, SHIM SHEETS IN INDIA.

Industrial sectors where Inconel 718 Sheets are used:

These sheets are widely used in fuel tanks, casings, and nuclear fuel element spacers. They are also used in aircraft and rocket engine components and applications. The uses of these Inconel 718 sheets are apt in fields of gas turbines and cryogenic storage tank components. They are also used in hot extrusion tooling. They are also used in the aerospace industry. They are also used in agricultural applications.

718 INCONEL SHEETS, INCONEL ALLOY 2.4668 SHEET, NICKEL ALLOY 718 SHEETS STOCKIST IN MUMBAI.

SMM Industries LLP is the best company that manufactures Inconel 718 Sheets in various grades, dimensions, and sizes per the application’s requirement. In addition, the company is the exporter and supplier of Inconel 718 Sheets worldwide.

Inconel 718 Sheets

Specification of Inconel 718 Sheets

Standard

ASTM B670/ ASME SB670

Thickness

0.3 mm to 120 mm

Width

1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc

Length

2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc

Tempers

Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard

Sheets Hardness

Half Hard, Quarter Hard, Soft, Hard, Spring Hard

Value added services for Sheets

Waterjet cutting, Plasma cutting, Laser cutting, Bending and mechanical processing, edge preparation, welding, sawing and shearing

Value Added Service

Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc.

Stock availability of Inconel 718 Sheets

Hot Rolled Sheets

Inconel 718 Hot Rolled Sheets

  • 718 Inconel HR Sheets
  • Alloy 718 Hot Rolled Sheets
  • 718 Inconel Hot Rolled Sheets
  • ASME SB 670 Inconel 718 HR Sheets
  • Inconel Alloy N07718 HR Sheets

Cold Rolled Sheets

Inconel 718 Cold Rolled Sheets

  • Inconel N07718 CR Sheets
  • 718 Inconel Cold Rolled Sheets
  • 718 Inconel CR Sheets
  • Alloy 718 Cold Rolled Sheets
  • ASME SB 670 Inconel Alloy 718 CR Sheets

Perforated Sheets

Inconel 718 Perforated Sheets

  • Inconel N07718 Perforated Sheets
  • ASME SB 670 Inconel Alloy 718 Perforated Sheets
  • 718 Inconel Perforated Sheets
  • Alloy 718 Perforated Sheets

Contact us to get a quick quote

If you require any further information, Please do not hesitate to contact us.
Contact Us

Equivalent Grades Inconel 718 Sheets

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
Inconel 718 2.4668 N07718 – – – – –

Chemical Composition of Inconel 718 Sheets

Grade C Mn Si S Cu Fe Ni Cr
Inconel 718 0.08 max 0.35 max 0.35 max 0.015 max 0.30 max – 50.00 – 55.00 17.00 – 21.00

Mechanical Properties of Inconel 718 Sheets

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Inconel 718 8.2 g/cm3 1350 °C (2460 °F) Psi – 1,35,000 , MPa – 930 Psi – 75,000 , MPa – 482 45 %

Inconel 718 Sheet Thickness Chart

Inconel Gauge Chart*
Gauge Number Inches MM
8 .17187 4.365
9 .15625 3.968
10 .14062 3.571
11 .125 3.175
12 .10937 2.778
14 .07812 1.984
16 .0625 1.587
18 .050 1.270
20 .0375 .9525
22 .03125 .7937
24 .025 .635
26 .01875 .476
28 .01562 .396
30 .0125 .3175

Inconel 718 Sheet Weight / Size

WEIGHT PER INCONEL SHEET :
THICKNESS IN MM SIZE IN MM WEIGHT KG/M2
2000 X 1000 2500 X 1250 3000 X 1500
0.18 2.88 – – 1.44
0.20 3.20 – – 1.60
0.22 3.52 – – 1.76
0.24 3.84 – – 1.92
0.27 4.32 – – 2.16
0.28 4.48 – – 2.24
0.32 5.12 – – 2.56
0.38 6.08 – – 3.04
0.44 7.04 11.00 – 3.52
0.50 8.00 12.50 – 4.00
0.56 8.96 14.00 – 4.48
0.63 10.08 15.75 – 5.04
0.75 12.00 18.75 – 6.00
0.88 14.08 22.00 – 7.04
1.00 16.00 25.00 36.00 8.00
.1.13 18.08 28.25 40.00 9.04
1.25 20.00 31.25 45.00 10.00
1.38 22.03 34.50 50.00 72.00
1.50 24.00 37.50 54.00 12.00
1.75 28.00 43.75 63.00 14.00
2.00 32.00 50.00 72.00 16.00
2.25 36.00 56.25 81.00 18.00
2.50 40.00 62.50 90.00 20.00
2.75 44.00 68.75 99.00 22.00
3.00 48.00 75.00 108.00 24.00
3.25 52.00 81.25 117.00 26.00
3.50 56.00 87.50 126.00 28.00
3.75 60.00 93.75 135.00 30.00
4.00 64.00 100.00 144.00 32.00
4.25 68.00 106.25 153.00 34.00
4.50 72.00 112.50 162.00 36.00
5.00 80.00 125.00 180.00 40.00
5.50 88.00 137.50 198.00 44.00
6.00 96.00 150.00 216.00 48.00
6.50 104.00 162.50 234.00 52.00
7.00 112.00 175.00 252.00 56.00
7.50 120.00 187.50 270.00 60.00
8.00 128.00 200.00 288.00 64.00

Inconel 718 Sheet Thickness Tolerance

Thickness
in. (mm)		 Sheet Width
36 (914.4)
in. (mm		 48 (1,219)
in. (mm)
0.017–0.030 (0.43–0.76) 0.0015 (0.038) 0.002 (0.051)
0.031–0.041 (0.79–1.04) 0.002 (0.051) 0.003 (0.076)
0.042–0.059 (1.1–1.5) 0.003 (0.076) 0.004 (0.10)
0.060–0.073 (1.5–1.9) 0.003 (0.076) 0.0045 (0.11)
0.074–0.084 (1.9–2.1) 0.004 (0.10) 0.0055 (0.14)
0.085–0.099 (2.2–2.5) 0.004 (0.10) 0.006 (0.15)
0.100–0.115 (2.5–2.9) 0.005 (0.13) 0.007 (0.18)
0.116–0.131 (2.9–3.3) 0.005 (0.13) 0.0075 (0.19)
0.132–0.146 (3.4–3.7) 0.006 (0.15) 0.009 (0.23)
0.147–0.187 (3.7–4.7) 0.007 (0.18) 0.0105 (0.2

Specialized In Following Inconel 718 Sheets

Nickel Alloy 718 Industrial Sheets Inconel Alloy 718 Sheet Dealer
Inconel 718 Sheets Cut to Size Alloy 718 Sheets Stockists
Inconel® Alloy 718 Sheets Supplier in India ASME SB 670 718 Inconel Sheets at Best Price
718 Inconel Sheets at Best Price Inconel Alloy Gr 718 Sheets
Inconel Alloy 718 Sheet Supplier Type 718 Inconel Sheets Standards
Alloy 718 Industrial Sheets Supplier Suppliers of 718 Inconel Sheets
718 Inconel Alloy Sheets ASTM B670 718 Inconel Sheets
Inconel 718 Sheets Exporter 718 Inconel Sheets Stockholder
Inconel 718 Sheet Manufacturer in India 718 Inconel Sheets Exporter
Inconel 2.4668 Sheets Cut To Size Inconel 718 Perforated Sheets Stockholder
718 Inconel Sheets Exporter in india 718 Inconel® Alloy Sheets
718 Inconel Sheets Dealer Nickel Alloy 718 Sheets Stockist
718 Inconel Sheets Supplier in Mumbai Alloy 718 Sheet Manufacturer in India

Searches Related to Inconel 718 Sheets

718 Inconel Sheet Price List, Inconel Alloy 718 Sheet Stockist In Mumbai, Inconel 718 Half Hard Sheets, Alloy 718 Sheet Exporter, 718 Inconel Sheets Length, Inconel Alloy 718 Sheet Price, Inconel 718 Sheet Stockyards In India, 718 Inconel Sheet Manufacturers, Inconel 718 Sheet Thickness Tolerance, 718 Inconel Sheets In Mumbai, Alloy 718 Sheet Exporter In India, Inconel 718 Sheets Catalogue, Inconel 718 Sheet Weight Calculator, Alloy 718 Sheets Chemical Composition, ASME SB 670 Inconel® Alloy 718 Sheet, 718 Inconel (HR) Hot Rolled Sheets Price List, Inconel Sheet Grade 718 Price List, Inconel 718 Sheets Manufacturer In Mumbai, Alloy 718 Inconel Sheets Thickness, Inconel 718 Sheet Price In India, Inconel 718 Sheets Best Price In Delhi, Inconel UNS N07718 Sheet, Buy Inconel® Alloy 718 Sheets Pdf, Alloy 718 Cold Rolled (CR) Sheets, 718 Inconel Sheet Dimensions, Inconel 718 Sheet Supplier In Mumbai, Cost Of 718 Inconel Sheet, Inconel 718 Sheet Price List In Mumbai, Inconel® Alloy 718 Sheets Price List In India, Inconel 718 Sheet Supplier, Inconel Alloy 718 Sheets Exporter, Price Of Inconel Alloy 718 Sheet, 718 Inconel Sheets Stocks, Inconel Alloy 718 sHEETS Supplier, Inconel 718 Sheet Price List, Inconel Alloy 718 Sheet Stockist, Inconel 718 Sheet Supplier In India, Inconel® Alloy 718 Sheets Price In Mumbai, Inconel 2.4668 Perforated Sheet Suppliers In Gujarat, Inconel 718 Sheet Weight, 718 Inconel Sheet Specifications, 718 Inconel Sheet Supplier In Mumbai, Inconel 718 Sheets Manufacturers In India, Price List Of Inconel 718 Sheets, 718 Inconel Latest Price, Inconel 718 Sheet Thickness Chart, Alloy 718 Sheet Price List, Inconel 718 Sheet Size, 718 Inconel Sheet In Pune, Inconel 718 Sheets In India, Cost Of Inconel 718 Sheets Exporter, Inconel Embossed Sheet, Inconel 718 Sheet Dealer In India, Inconel Alloy 718 Hot Rolled Sheets Price List, Inconel 718 Sheet Manufacturers, Inconel 718 Sheets Supplier In India, Inconel 718 Sheets Equivalent Grades, Inconel 718 Sheets Price, Inconel Alloy 718 Sheet Supplier IN mUMBAI, Top 100 Inconel Sheet Dealers In Pune, Inconel 718 Bright Annealed Price In India.
