Stainless Steel 317L tubes contain carbon, manganese, silicon, chromium, nickel, molybdenum, phosphorus, sulfur, and iron. The combination of molybdenum in stainless Steel Tube 317L makes it more corrosion-resistant. The presence of molybdenum also improves the resistance of Stainless Steel 317L tubing to chlorides.

317L STAINLESS STEEL ERW AND SEAMLESS TUBES MANUFACTURER IN MUMBAI, INDIA.

Stainless Steel 317L Tubes have the following features:

These tubes have a high melting range and high density.
The tubes possess good tensile and yield stress properties. It is conceivable to forge Stainless Steel 317 L Tubes without worrying about their sensitizing owing to rust damage by chromium carbide precipitation at crystalline structure due to its low carbon content.
They have excellent resistance to fracturing and cracking under elevated temperatures.
These tubes have solid thermal conductivity and a significant mean coefficient of thermal expansion.

These tubes also possess excellent electrical resistance.
The weldability and formability of these 317L tubes are excellent.
They can bear heavy haulage and stress.
These tubes are highly reliable.
They perform well in saline and brine solutions.

These 317L tubes are resistant to galling and pitting.

STOCKIST OF ASTM A269 TP317L TUBES MUMBAI, COMPETITIVE PRICE OF JINDAL STAINLESS STEEL 317L TUBE, WE EXPORTER SS 317L ERW, SEAMLESS, RECTANGULAR, HEAT-EXCHANGER AND WELDED TUBES IN INDIA.

Stainless Steel 317L Tubes can be used in a variety of applications:

Chemical and petrochemical process equipment, pulp and paper manufacture, and condensers in fossil and nuclear-fueled power generation facilities are the industries that utilize

Stainless Steel 317L tubes. These tubes are also designed for usage in the industrial and automotive industries. Stainless Steel 317L tubes are often used in power plants, paper, and pulp processing plants. They are also used in textile equipment, petrochemical processing plants, food processing plants, flue gas desulfurization scrubbers, and chemical processing plants. These tubes are also in marine industries.

SMM Industries LLP is a manufacturer, exporter, and trader of Stainless Steel 317L Tubes in a broad range of sizes. The offered goods are created using the highest quality components and best production technologies. Supplied varieties of goods, employed for their conductive capabilities, are well-known among valued clients for their exquisite finish, superior performance, and durable construction.

ASTM A249 TP317L CUSTOM, WELDED TUBES PRICE LIST PER METER, SS 317L SUPERHEATER, SQUARE SPECIFICATIONS, LARGEST STOCKHOLDER OF JINDAL STAINLESS STEEL 317L TUBING STOCKIST IN MUMBAI.

Specification of Stainless Steel 317L Tubes

Specifications

ASTM A213, A269, A249 / ASME SA213, SA269, SA249

Schedule Thickness Range

SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS

Dimensions

ASTM, ASME and API

End Types

Plain End, Beveled End, Treaded One End, TBE (Treaded Both Ends)

Size

1/2" NB - 24" NB

Delivery Condition

Annealed and Pickled, Polished, Bright Annealed, Cold Drawn

Thickness

Schedule 5S - Schedule XXS.

Surface Finish

No.1, No.4, No.8 Mirror Finish, 2B

Manufacturing Shapes

Round, Rectangle, Square, Hex

Value Added Services

Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing

Manufacturing Techniques

Seamless / Welded / ERW / Fabricated

Outside Finish

2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Tubes, Finish as per customer Requirements

Delivery Condition

Annealed and Pickled, Polished, Bright Annealed, Cold Drawn

Specials

Sizes and Specifications other than above can be on request

Stock availability of STAINLESS sTEEL 317L Tubes

Contact us to get a quick quote

If you require any further information, Please do not hesitate to contact us.

Equivalent Grades Stainless Steel 317 Tubes

STANDARD	WERKSTOFF NR.	UNS	JIS	EN
SS 317L	1.4438	S31703	SUS 317L	X2CrNiMo18-15-4

Chemical Composition of Stainless Steel 317 Tubes

Grade	C	Mn	Si	P	S	Cr	Mo	Ni	Fe
SS 317L	0.035 max	2.0 max	1.0 max	0.045 max	0.030 max	18.00 – 20.00	3.00 – 4.00	11.00 – 15.00	57.89 min

Mechanical Properties of Stainless Steel TP 317 Tubes

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
7.9 g/cm3	1400 °C (2550 °F)	Psi – 75000 , MPa – 515	Psi – 30000 , MPa – 205	35 %

Stainless Steel 317 Tubes Dimensions

TUBE O.D.	WALL THICKNESS (INCHES)
	TUBE GAUGE
	00	0	1	2	3	4	5	6	7	8	9	10	11	12	13	14	15	16	17	18	19	20	21	22	23	24
	TUBE I.D.
	0.380	0.340	0.300	0.284	0.259	0.238	0.220	0.203	0.180	0.165	0.148	0.134	0.120	0.109	0.095	0.083	0.072	0.065	0.058	0.049	0.042	0.035	0.032	0.028	0.025	0.022
1/4″	N/A	N/A	N/A	N/A	N/A	N/A	N/A	N/A	N/A	N/A	N/A	N/A	0.010	0.032	0.060	0.084	0.106	0.120	0.134	0.152	0.166	0.180	0.186	0.194	0.200	0.206
3/8″	N/A	N/A	N/A	N/A	N/A	N/A	N/A	N/A	0.015	0.045	0.079	0.107	0.135	0.157	0.185	0.209	0.231	0.245	0.259	0.277	0.291	0.305	0.311	0.319	0.325	0.331
1/2″	N/A	N/A	N/A	N/A	N/A	0.024	0.060	0.094	0.140	0.170	0.204	0.232	0.260	0.282	0.310	0.334	0.356	0.370	0.384	0.402	0.416	0.430	0.436	0.444	0.450	0.456
5/8″	N/A	N/A	0.025	0.057	0.107	0.149	0.185	0.219	0.265	0.295	0.329	0.357	0.385	0.407	0.435	0.459	0.481	0.495	0.509	0.527	0.541	0.555	0.561	0.569	0.575	0.581
3/4″	N/A	0.070	0.150	0.182	0.232	0.274	0.310	0.344	0.390	0.420	0.454	0.482	0.510	0.532	0.560	0.584	0.606	0.620	0.634	0.652	0.666	0.680	0.686	0.694	0.700	0.706
7/8″	0.115	0.195	0.275	0.307	0.357	0.399	0.435	0.469	0.515	0.545	0.579	0.607	0.635	0.657	0.685	0.709	0.731	0.745	0.759	0.777	0.791	0.805	0.811	0.819	0.825	0.831
1″	0.240	0.320	0.400	0.432	0.482	0.524	0.560	0.594	0.640	0.670	0.704	0.732	0.760	0.782	0.810	0.834	0.856	0.870	0.884	0.902	0.916	0.930	0.936	0.944	0.950	0.956
1 1/8″	0.365	0.445	0.525	0.557	0.607	0.649	0.685	0.719	0.765	0.795	0.829	0.857	0.885	0.907	0.935	0.959	0.981	0.995	1.009	1.027	1.041	1.055	1.061	1.069	1.075	1.081
1 1/4″	0.490	0.570	0.650	0.682	0.732	0.774	0.810	0.844	0.890	0.920	0.954	0.982	1.010	1.032	1.060	1.084	1.106	1.120	1.134	1.152	1.166	1.180	1.186	1.194	1.200	1.206
1 1/2″	0.740	0.820	0.900	0.932	0.982	1.024	1.060	1.094	1.140	1.170	1.204	1.232	1.260	1.282	1.310	1.334	1.356	1.370	1.384	1.402	1.416	1.430	1.436	1.444	1.450	1.456
1 3/4″	0.990	1.070	1.150	1.182	1.232	1.274	1.310	1.344	1.390	1.420	1.454	1.482	1.510	1.532	1.560	1.584	1.606	1.620	1.634	1.652	1.666	1.680	1.686	1.694	1.700	1.706
2″	1.240	1.320	1.400	1.432	1.482	1.524	1.560	1.594	1.640	1.670	1.704	1.732	1.760	1.782	1.810	1.834	1.856	1.870	1.884	1.902	1.916	1.930	1.936	1.944	1.950	1.956
2 1/4″	1.490	1.570	1.650	1.682	1.732	1.774	1.810	1.844	1.890	1.920	1.954	1.982	2.010	2.032	2.060	2.084	2.106	2.120	2.134	2.152	2.166	2.180	2.186	2.194	2.200	2.206
2 1/2″	1.740	1.820	1.900	1.932	1.982	2.024	2.060	2.094	2.140	2.170	2.204	2.232	2.260	2.282	2.310	2.334	2.356	2.370	2.384	2.402	2.416	2.430	2.436	2.444	2.450	2.456
2 3/4″	1.990	2.070	2.150	2.182	2.232	2.274	2.310	2.344	2.390	2.420	2.454	2.482	2.510	2.532	2.560	2.584	2.606	2.620	2.634	2.652	2.666	2.680	2.686	2.694	2.700	2.706
3″	2.240	2.320	2.400	2.432	2.482	2.524	2.560	2.594	2.640	2.670	2.704	2.732	2.760	2.782	2.810	2.834	2.856	2.870	2.884	2.902	2.916	2.930	2.936	2.944	2.950	2.956
3 1/4″	2.490	2.570	2.650	2.682	2.732	2.774	2.810	2.844	2.890	2.920	2.954	2.982	3.010	3.032	3.060	3.084	3.106	3.120	3.134	3.152	3.166	3.180	3.186	3.194	3.200	3.206
3 1/2″	2.740	2.820	2.900	2.932	2.982	3.024	3.060	3.094	3.140	3.170	3.204	3.232	3.260	3.282	3.310	3.334	3.356	3.370	3.384	3.402	3.416	3.430	3.436	3.444	3.450	3.456
3 3/4″	2.990	3.070	3.150	3.182	3.232	3.274	3.310	3.344	3.390	3.420	3.454	3.482	3.510	3.532	3.560	3.584	3.606	3.620	3.634	3.652	3.666	3.680	3.686	3.694	3.700	3.706
4″	3.240	3.320	3.400	3.432	3.482	3.524	3.560	3.594	3.640	3.670	3.704	3.732	3.760	3.782	3.810	3.834	3.856	3.870	3.884	3.902	3.916	3.930	3.936	3.944	3.950	3.956
4 1/4″	3.490	3.570	3.650	3.682	3.732	3.774	3.810	3.844	3.890	3.920	3.954	3.982	4.010	4.032	4.060	4.084	4.106	4.120	4.134	4.152	4.166	4.180	4.186	4.194	4.200	4.206
4 1/2″	3.740	3.820	3.900	3.932	3.982	4.024	4.060	4.094	4.140	4.170	4.204	4.232	4.260	4.282	4.310	4.334	4.356	4.370	4.384	4.402	4.416	4.430	4.436	4.444	4.450	4.456
4 3/4″	3.990	4.070	4.150	4.182	4.232	4.274	4.310	4.344	4.390	4.420	4.454	4.482	4.510	4.532	4.560	4.584	4.606	4.620	4.634	4.652	4.666	4.680	4.686	4.694	4.700	4.706
5″	4.240	4.320	4.400	4.432	4.482	4.524	4.560	4.594	4.640	4.670	4.704	4.732	4.760	4.782	4.810	4.834	4.856	4.870	4.884	4.902	4.916	4.930	4.936	4.944	4.950	4.956
5 1/4″	4.490	4.570	4.650	4.682	4.732	4.774	4.810	4.844	4.890	4.920	4.954	4.982	5.010	5.032	5.060	5.084	5.106	5.120	5.134	5.152	5.166	5.180	5.186	5.194	5.200	5.206

Stainless Steel 317 Tubing Size

Wall Thickness	Monel Tube Sizes ( O.D.)
.010	1/16″ , 1/8″ , 3/16″
.020	1/16″ , 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″
.012	1/8″
.016	1/8″ , 3/16″
.028	1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 3/4″ , 1″ , 1 1/2″ , 2″
.035	1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 7/16″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″
.049	3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/8″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″
.065	1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 3/4″ , 2″ , 2 1/2″ , 3″
.083	1/4″ , 3/8″ , 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 7/8″ , 2″ , 2 1/2″ ,3″
.095	1/2″ , 5/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″
.109	1/2″ , 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″
.120	1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 2 1/4″ , 2 1/2″ , 3″
.125	3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 3″ , 3 1/4″
.134	1″
.250	3″
.375	3 1/2″

Stainless Steel 317 Tubes Pressure Rating

Tube O.D. (in.)	Wall Thickness of Tube (inches)
	.028	.035	.049	.065	.083	.095	.109	.120
	Working Pressure (psig)
1/8	7900	10100
1/4	3700	4800	7000	9500
5/16		3700	5400	7300
3/8		3100	4400	6100
1/2		2300	3200	4400
3/4			2200	3000	4000	4600
1				2200	2900	3400	3900	4300

Specialized in Following Stainless Steel 317 Tubes

317L Stainless Steel Hollow Tubing	Stainless Steel Grade 317L Hydraulic Tube
Stainless Steel 317L Elliptical Tube	SS Grade 317L Industrial Tubes
Stainless Steel 317L Polished Tubing	ASME SA 213 317L SS Seamless Tubes at Best Price
High Pressure Stainless Steel 317L Tubes	Stainless Steel Gr 317L U Tubes
317L Stainless Steel Tubes Supplier in Mumbai	SS 317L Customized Tube Manufacturer in India
317L SS Square Tubes Dealer	Stainless Steel 317L Tubes Stockist
AISI 317L U Shaped Tubes	ASTM A270 SS 317L Sanitary Tubes
SS 317L Industrial Tubing Supplier	Suppliers of 317L Stainless Steel ERW Tubing
Stainless Steel 317L Condenser Tubing Exporter	317L Stainless Steel Needle Tubes Stockholder
Stainless Steel 1.4438 Tubes Cut To Size	Stainless Steel 317L Perforated Tubing
Stainless Steel 317L Decorative Tube	317L Stainless Steel Tubing Exporter in india
Stainless Steel 317L Rectangular Tube	Stainless Steel 317L Corrugated Tube Dealer
317L Stainless Steel Superheater Tubes	317L Stainless Steel Thin Wall Tubes
317L Stainless Steel Ornamental Tubing	SS 317L Thin Wall Tubes Stockists
Stainless Steel 317L Tube Supplier	Type 317L Stainless Steel Tubes Standards
SS 317L Tube Manufacturer in India	Austenitic Stainless Steel 317L Tubing
317L Austenitic Stainless Steel Tubing	Stainless Steel 317L Capillary Tubes
INOX 317L Stainless Steel Tubes	317L Seamless Stainless Steel Tubes Exporter
317L Welded Stainless Steel Tubes	ASTM A269 TP317L Stainless Steel Tubing
317L SS Electric Resistance Welded Tubing at Best Price	Stainless Steel Gr 317L Mechanical Tubing
