Titanium Grade 5 Coils are manufactured and marketed by SMM Industries LLP. We use our best mill connections to supply the finest quality Titanium Grade 5 Coils at the comparative market price. According to national norms, we create these coils with the utmost attention to material quality. As a result, our coils are sold in several nations for an extensive application range.

Titanium Grade 5 Coils composition and characteristics are listed below:

Titanium Grade 5 coils are made up of the proper chemical compositions of Titanium, Iron, Carbon, Oxygen, Hydrogen, Nitrogen, Aluminum, and Vanadium. The Titanium Grade 5 material is made up of a two-phase alloy called alpha and beta phases in the crystalline structure. The company coils are an excellent blend of toughness and strength.

Titanium Alloy N56400 Coils, Titanium Grade 5 Coils, Titanium 3.7165 Coils, UNS N56400 Coils, Ti Alloy Grade 5 HR Coils, 3.7165 Coils, Gr 5 Titanium Coils Manufacturer, Titanium Grade 5 Cold Rolled Coils, Gr 5 Titanium Coils, Ti Alloy Gr. 5 Industrial Coils, Ti Alloy Grade 5 Coils Supplier in Mumbai, India

The basic characteristics of Titanium Grade 5 Coils are as follows:

Titanium Grade 5 is the most commonly used grade of coils. While it has the same rigidity and thermal qualities as commercially pure titanium, it is significantly more powerful, excluding thermal conductivity lower in Grade 5 Titanium. It is heat treatable, which is one of its numerous benefits.

The company’s product of coils has high-quality features of long-lasting performance and higher tensile strength with dimensional accuracy.
These Titanium Grade 5 Coils possess characteristics of very high yielding strength at low-density coils, lower weight, higher melting temperature, and excellent elongation strength.
Grade 5 combines good strength, excellent corrosion resistance, weldability, and fabricability.

Titanium Alloy N56400 Coils, Titanium Grade 5 Coils, India., UNS N56400 Coils, Titanium Grade 5 Cold Rolled Coils, Titanium 3.7165 Coils, Ti Alloy Grade 5 Coils Supplier in Mumbai, Gr 5 Titanium Coils Manufacturer, Ti Alloy Gr. 5 Industrial Coils, 3.7165 Coils, Gr 5 Titanium Coils, Ti Alloy Grade 5 HR Coils

Titanium Grade 5 Coils have significant benefits as follows:

The Titanium Grade 5 Coils can withstand both cryogenic and high temperatures of up to 427 ° C. The material may be used in annealed or solid solution heated conditions. At ambient temperatures, coils have outstanding ductile properties and offer a good drag barrier up to 570 °F. These coils are resistant to thermal corrosion and replace heavy applications due to their lower weight.

Titanium Grade 5 Coils shows common utilities as listed below:

Aerospace, medical, maritime, and chemical processing
Connecting rods for combustion engines and surgical implants
Automotive, power generation, oil and gas extraction
Refineries, petrochemicals, chemicals, pharmaceutical
Sugar, nuclear, thermal pipe plants, and engineering

Ti Alloy Gr. 5 Coils, Ti Alloy Grade 5 Coils Price List, Titanium Alloy 3.7165 Coil, Ready Stock of Gr 5 Titanium Coils, Titanium Gr. 5 Coils Stockist in Mumbai., Largest Stockholder of Titanium Gr 5 Coils in India, Titanium Alloy Grade 5 Coils,

Specification of Titanium Grade 5 Coils

Standard

ASTM B265 / ASME SB265

Thickness

0.2mm – 5.0mm

Width

3.2mm – 1500mm

Length

AS PER CUSTOMER’S REQUIREMENT

Tempers

Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard

Coil Hardness

Half Hard, Quarter Hard, Soft, Hard, Spring Hard

Value added services for Coils

Waterjet cutting, Plasma cutting, Laser cutting, Bending and mechanical processing, edge preparation, welding, sawing and shearing

Form

Coil / Strip.

Stock availability of Titanium Grade 5Coils

Contact us to get a quick quote

If you require any further information, Please do not hesitate to contact us.

Equivalent Grades Titanium Grade 5 Coils

STANDARD	WERKSTOFF NR.	UNS
Titanium Grade 5	3.7165	N56400

Chemical Composition of Titanium Grade 5 Coils

Grade	Ti	C	Fe	O	Al	V
Titanium Gr 5	90 min	–	0.25 max	0.2 max	6 min	4 min

Mechanical Properties of Titanium Grade 5 Coils

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
4.43 g/cm3	1632 °C (2970 °F)	Psi – 138000 , MPa – 950	Psi – 128000 , MPa – 880	14 %

Titanium Grade 5 Coils Thickness Chart

Titanium Gauge Chart*
Gauge Number	Inches	MM
8	.17187	4.365
9	.15625	3.968
10	.14062	3.571
11	.125	3.175
12	.10937	2.778
14	.07812	1.984
16	.0625	1.587
18	.050	1.270
20	.0375	.9525
22	.03125	.7937
24	.025	.635
26	.01875	.476
28	.01562	.396
30	.0125	.3175

Titanium Grade 5 Coils Weight / Size

WEIGHT PER TITANIUM GRADE 5 COILS :
THICKNESS IN MM	SIZE IN MM			WEIGHT KG/M2
THICKNESS IN MM	2000 X 1000	2500 X 1250	3000 X 1500	WEIGHT KG/M2
0.18	2.88	–	–	1.44
0.20	3.20	–	–	1.60
0.22	3.52	–	–	1.76
0.24	3.84	–	–	1.92
0.27	4.32	–	–	2.16
0.28	4.48	–	–	2.24
0.32	5.12	–	–	2.56
0.38	6.08	–	–	3.04
0.44	7.04	11.00	–	3.52
0.50	8.00	12.50	–	4.00
0.56	8.96	14.00	–	4.48
0.63	10.08	15.75	–	5.04
0.75	12.00	18.75	–	6.00
0.88	14.08	22.00	–	7.04
1.00	16.00	25.00	36.00	8.00
.1.13	18.08	28.25	40.00	9.04
1.25	20.00	31.25	45.00	10.00
1.38	22.03	34.50	50.00	72.00
1.50	24.00	37.50	54.00	12.00
1.75	28.00	43.75	63.00	14.00
2.00	32.00	50.00	72.00	16.00
2.25	36.00	56.25	81.00	18.00
2.50	40.00	62.50	90.00	20.00
2.75	44.00	68.75	99.00	22.00
3.00	48.00	75.00	108.00	24.00
3.25	52.00	81.25	117.00	26.00
3.50	56.00	87.50	126.00	28.00
3.75	60.00	93.75	135.00	30.00
4.00	64.00	100.00	144.00	32.00
4.25	68.00	106.25	153.00	34.00
4.50	72.00	112.50	162.00	36.00
5.00	80.00	125.00	180.00	40.00
5.50	88.00	137.50	198.00	44.00
6.00	96.00	150.00	216.00	48.00
6.50	104.00	162.50	234.00	52.00
7.00	112.00	175.00	252.00	56.00
7.50	120.00	187.50	270.00	60.00
8.00	128.00	200.00	288.00	64.00

Titanium Grade 5 Coil Thickness Tolerance

Thickness in. (mm)	Coil Width
Thickness in. (mm)	36 (914.4) in. (mm	48 (1,219) in. (mm)
0.017–0.030 (0.43–0.76)	0.0015 (0.038)	0.002 (0.051)
0.031–0.041 (0.79–1.04)	0.002 (0.051)	0.003 (0.076)
0.042–0.059 (1.1–1.5)	0.003 (0.076)	0.004 (0.10)
0.060–0.073 (1.5–1.9)	0.003 (0.076)	0.0045 (0.11)
0.074–0.084 (1.9–2.1)	0.004 (0.10)	0.0055 (0.14)
0.085–0.099 (2.2–2.5)	0.004 (0.10)	0.006 (0.15)
0.100–0.115 (2.5–2.9)	0.005 (0.13)	0.007 (0.18)
0.116–0.131 (2.9–3.3)	0.005 (0.13)	0.0075 (0.19)
0.132–0.146 (3.4–3.7)	0.006 (0.15)	0.009 (0.23)
0.147–0.187 (3.7–4.7)	0.007 (0.18)	0.0105 (0.2
