Manufacturing and specifications of Inconel 601 Plates vary as per the needs of applications, such as thicknesses, sizes, shapes, weights, lengths, etc. With the help of outstanding characteristics such as corrosion resistivity, there are diverse applications where Inconel 601 Plates are used. We provide these Inconel 601 plates with great material combinations for application sectors where high strength and surface finish are required.

What is Inconel 601 grade?

Inconel 601 is a nickel and chromium-based alloy grade employed for corrosion and heat resistance. Inconel 601 alloy has good resistance to aqueous corrosion and high mechanical strength and is readily formed, machined, and welded.

INCONEL ALLOY N06601 PLATES, ALLOY 601 HR PLATES, AND INCONEL 601 COLD ROLLED PLATES ARE MANUFACTURED IN MUMBAI, INDIA.

Different Properties of Inconel 601 Plates material:

Inconel 601 Plates are manufactured with an alloy consisting of nickel and chromium elements. This Nickel Chromium-based Inconel 601 plate also has an Aluminium element. The aluminium present in it gives outstanding resistance to oxidation and resistance to other forms of corrosion.

These Inconel 601 Plates provide good creep rupture strength. Also, the alloy used for manufacturing these Inconel 601 Plates can be widely used in manufacturing equipment that needs to withstand high temperatures. The Inconel 601 Plates are helpful for higher temperature applications, which are improved by their resistance against oxidation and other corrosion.

COMPETITIVE PRICE OF ASME SB 433 601 INCONEL PLATES ALLOY 601 CR PLATE, NICKEL ALLOY 601 PLATES EXPORTER IN INDIA.

Attributes of Inconel 601 Plates:

  • They have metallurgical stability
  • These plates come with high resistance to carburization
  • They have excellent oxidation resistance to 2200° F
  • They come with the best creep rupture strength
  • Inconel 601 Plates resist even under severe thermal cycling conditions



Mechanical properties of Inconel 601 Plates:

  • Density
  • Tensile strength
  • Yield strength
  • Elongation
  • Hardness

These are the different mechanical properties of these plates.



 The different applications where Inconel 601 Plates are used:

  • Airframes
  • Aerospace engine components
  • Thrust reversers
  • Hot-air duct systems
  • Pressure vessels
  • Gas turbines
  • Turbine blades, seals, and rotors
  • Bolts
  • Forming tools
  • Extrusion dies

INCONEL 601 HOT ROLLED PLATES, INCONEL 601 PLATES IN INDIA, INCONEL ALLOY 601 PLATES STOCKIST IN MUMBAI.

SMM Industries LLP is the best company that provides supreme quality Inconel 601 Plates. These Inconel 601 plates are entirely manufactured concerning standard guidelines of manufacturing. These are the best to work with all sorts of applications as they are manufactured in customized and default forms.

Inconel 601 Plates

Specification of Inconel 601 Plates

Standard

ASTM B433/ ASME SB433

Thickness

0.3 mm to 120 mm

Width

1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc

Length

2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc

Processing Types

Hot Rolled plate, Cold Roleled Plate

Sheets Hardness

Half Hard, Quarter Hard, Soft, Hard, Spring Hard

Value added services for Plates

Waterjet cutting, Plasma cutting, Laser cutting, Bending and mechanical processing, edge preparation, welding, sawing and shearing

Value Added Service

Cladding, Heat Treatment, Annealed, Pickling, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc.

Stock availability of Inconel 601 Plates

Hot Rolled Plates

Inconel 601 Hot Rolled Plates

  • Inconel 601 Hot Rolled Plates
  • UNS N06601 Hot Rolled Plate
  • ASME SB 433 601 Inconel HR Plates
  • 601 Inconel HR Plates
  • Nickel Alloy 601 Hot Rolled Plates
  • Inconel Alloy 601 Hot Rolled Plates
  • Inconel N06601 HR Plates

Cold Rolled Plates

Inconel 601 Cold Rolled Plates

  • Inconel N06601 CR Plates
  • Nickel Alloy 601 Cold Rolled Plates
  • Inconel 601 Cold Rolled Plates
  • ASME SB 433 601 Inconel CR Plates
  • UNS N06601 Cold Rolled Plate
  • 601 Inconel CR Plates
  • Inconel Alloy 601 Cold Rolled Plates

Chequered Plates

Inconel 601 Custom Plates

  • UNS N06601 Custom Plate
  • ASME SB 433 601 Inconel Custom Plates
  • Nickel Alloy 601 Custom Plates
  • Inconel® Alloy 601 Custom Plates
  • 601 Inconel Custom Plates
  • Inconel N06601 Custom Plates

Contact us to get a quick quote

If you require any further information, Please do not hesitate to contact us.
Contact Us

Equivalent Grades Inconel 601 Plates

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
Inconel 601 2.4851 N06601 NCF 601 NA 49 XH60BT NC23FeA NiCr23Fe

Chemical Composition of Inconel 601 Plates

Grade C Mn Si S Cu Fe Ni Cr
Inconel 601 0.10 max 1.0 max 0.5 max 0.015 max 1.0 max Balance 58.0 – 63.0 21.0 – 25.0

Mechanical Properties of Inconel 601 Plates

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Inconel 601 8.1 g/cm3 1411 °C (2571 °F) Psi – 80,000 , MPa – 550 Psi – 30,000 , MPa – 205 30 %

Inconel 601 Plates Weight Per Unit

Weight of Plate Thickness in inches
0.08 lbs/in²56.245568 kg/m² 1/4
0.06000 lbs/in²42.184176 kg/m² 3/16
0.161 lbs/in²113.1942056 kg/m² 1/2
0.121 lbs/in²85.0714216 kg/m² 3/8
0.391 lbs/in²274.9002136 kg/m² 1 1/4
0.235 lbs/in²165.221356 kg/m² 3/4
0.196 lbs/in²137.8016416 kg/m² 5/8
0.313 lbs/in²220.0607848 kg/m² 1
0.627 lbs/in²440.8246392 kg/m² 2
0.941 lbs/in²661.5884936 kg/m² 3
0.274 lbs/in²192.6410704 kg/m² 7/8
0.862 lbs/in²606.0459952 kg/m² 2 3/4
0.549 lbs/in²385.9852104 kg/m² 1 3/4
0.47 lbs/in²330.442712 kg/m² 1 1/2
0.784 lbs/in²551.2065664 kg/m² 2 1/2
0.705 lbs/in²495.664068 kg/m² 2 1/4

Inconel 601 Plates Weight / Size

Stocked Sizes
Size (in inches)
Size (in mm)
.125″
3.18mm
.134″
3.40mm
.156″
3.96mm
.187″
4.75mm
.250″
6.35mm
.312″
7.92mm
.375″
9.53mm
.500″
12.7mm
.600″
15.9mm
.750″
19.1mm
.875″
22.2mm
1″
25.4mm
1.125″
28.6mm
1.250″
31.8mm
1.500″
38.1mm
1.750″
44.5mm
2″
50.8mm
2.500″
63.5mm
3″
76.2mm

Inconel 601 Plates Thickness Tolerance

Tolerance over and under nominal thickness t (mm)
Width w (mm) 2.54.56.08.010.012.516.020.025.030
w < 1200 0.20 0.23 0.30 0.32 0.35 0.80 0.80 0.80 1.0 1.4
1200< w <1500 0.20 0.25 0.30 0.35 0.38 0.80 0.80 0.90 1.0 1.4
1500< w <1800 0.20 0.28 0.32 0.38 0.40 0.80 0.80 0.90 1.1 1.5
1800< w <2100 0.20 0.30 0.36 0.40 0.45 0.80 0.80 0.90 1.1 1.5
2100< w <2400 0.80 0.80 0.80 0.80 0.80 0.90 1.0 1.1 1.5
2400< w <2700 0.80 0.80 0.80 0.80 0.90 1.0 1.1 1.3 1.7
2700< w <3000 0.80 0.90 1.0 1.0 1.0 1.1 1.3 1.4 1.8

Specialized In Following Inconel 601 Plates
